| Working Parameters |
| Light Source |
650nm high strength laser diode |
| Scan Distance |
0~206mm @ UPC/EAN PCS=90% |
| Scan Angle |
5 |
| Scan Beam |
20 |
| Scan Speed |
1400 scan lines/sec |
| Min.Resolution |
0.1mm(4mil)@Code 39, PCS=90% |
| Print Contrast Signal |
>30%(UPC/EAN 100%) |
| LED Indication |
blue + red |
| Sound |
adjustable buzzer |
| Communication Interface |
HID USB, USB Virtual COM, RS-232 serial port |
| Physical Parameters |
| Dimension |
82mmx82mmx155mm |
| Weight |
320g (data line not included) |
| Wire Length |
2.0m |
| Power Supply Parameters |
| Input Voltage |
5VDC±10% |
| Working Current |
220mA |
| Environment Parameters |
| Operating Temperature |
0℃~+50℃ |
| Operating Humidity |
5%~95% no condensation |
| Storage Temperature |
-20℃~+60℃ |
| Ambient Brightness |
0~4,000Lux（fluorescence），0~100,000Lux（sunlight） |
| Safety Standards |
| EMC |
CE EN55022 B, FCC Part 15 Class B, VCCI, BSMI |
| Laser Safety |
CDRH Class IIa, IEC 60825-1 Class 1 |
| Decode Type |
|
UPC/EAN/JAN,UPC-A & UPC-E,EAN-8 & EAN-13, JAN-8 &JAN-13, ISBN/ISSN, Code 39 (with full ASCII), Codabar (NW7), Code 128 & EAN 128,Code 93,Interleaved 2 of 5 (ITF),Addendum 2 of 5, IATA Code,MSI/Plessy, China Postal Code,Code 32 (Italian Pharmacode),RSS 14,RSS Limited, RSS Expanded |
